Applications:
Pharmaceutical, BioProcessing
Controls:
Fixed Controls
Temp Range:
+40°C to -85°C
Storage:
23.3 cu ft / 659.8 l
Electrical:
400 VAC, 3 Ø, 50Hz, 24 FLA (International)
Performance Data:
Pull Down Empty Chamber < 38 minutes from +25˚C to –80˚C Door Open Recovery @ –80˚C < 10 minutes 100L Load +25˚C to –80˚C < 12 Hours Uniformity Air Temperature +/- 2.0˚C Uniformity Product Temperature +/- 1.0˚C
Refrigeration System:
Heat Transfer Convection, Air Flow
High Stage R-449A
Low Stage R-508B
Defrost Auto defrost program, EZ1 Key Touch
Heat of Rejection – Air Cooled 38,000 BTU/hr (11 kW/hr)
Heat of Rejection – Water Cooled 1,700 BTU/hr (0.5 kW/hr)
