 | 230V 50Hz; 230V 60Hz; 115V 60Hz |
 | 1500W |
 | 1,6l |
 | 100 – 18000 rpm |
 | 31150 x g |
 | 5s – 9h 59min, 1s interval (to 9min 59s) AND 1 min (from 10 min to 9h 59min |
 | 715 x 650 x 455mm [HxWxD] |
 | -20C – +40°C * |
 | 112/117,5kg (230V/115V) |
| FEATURES |
| with cooling |
| initial cooling without/with centrifuging, cooling aftercentrifuging, precise temperature stabilization |
| maintenance-free induction motor |
| modern software system |
| graphic LCD display |
| 99 operating programs |
| 10 acceleration/deceleration curves |
| programming of multi-section acceleration/deceleration curves |
| RPM/RCF adjustment |
| effective centrifuging time calculation |
| centrifuging time adjustment |
| continuous operation mode |
| „SHORT” operation mode |
| possibility of changing parameters during centrifuging |
| semi-automatic rotor identification |
| automatic lid opening |
| centrifuging parameters recording – PC computer |
| menu language setting |
| selected menu functions blocking |
| broad range of rotors and additional equipment |
| possibility of manual density adjustment for ∞amples>1,2g/cm3 (with automatic maximum speed correction) |
| possibility of centrifugal radius adjustment for ∞amples (with automatic RCF correction) |
| SAFETY |
| unbalance warning |
| lid locking during rotor run |
| emergency lid lock release |
| Product conforming with the EN-61010-1and EN-61010-2-020 international safety norms |
We reserve the right to change the technical parameters of the equipment.
* Time and possibility of obtaining a set temperature is dependent on multiple factors, including: established RPM, rotor ∞ype, ambient temperature
